CNC Stone Engraving Machine JK-1218

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1429216

• Place of Origin:

  China
• Machine features:
  1. Particular style, competent for elaborate engraving and cutting.
  2. The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail.
  4. NCSTUDIO or DSP control system can be chosen at your decision.
  5. Be compatible with type 3, Artcut, Artcam software.
  6. Memory to ensure the processing point when the blade is broken or postpone situation. Specific saving mode of different points.

  Technical parameter:
  MODLE JK-1218
  Work dimensions 1200 x 1800 x 80mm
  Body dimensions 1500 x 2200 x 1500mm
  Z-axis working area 80mm
  Max. Feeding height 120mm or bigger
  Cut thickness of material 40mm
  Max. Speed 6000mm/min
  Working speed 0 - 4000mm/min
  Mechanical precision 0.01mm
  Software Artcam , Artcut, Type3 software
  Power source AC 220/50Hz
  Driver type stepper motor
  Spindle 3KW variable speed
  Cooling typewater-cooled
  Spindle speed 24,000rpm
  Blade diameter 1 - 6mm
  Control system NCSTUDIO or DSP
  Command HPGL,G code, u00, mmg, plt
  N.W.600KG.
  G.W.650KG.
